Formlabs Form Cure (Second Generation)
Formlabs Form Cure (Second Generation)
Product Specifications
Product Specifications
Product Description
Post-curing completes the chemical reaction started during printing, enhancing final part strength, toughness, heat resistance, and creep resistance while creating a harder, less tacky surface. The Form Cure (2nd Generation) precisely combines heat and 405nm light to deliver tough, strong prints with unprecedented speed and consistency. Now you can post-cure Form 4/B prints in as little as 60 seconds, with 4 times more UV power, 5 times faster heat-up times, and a third larger chamber. To begin curing, just select a validated preset for any of the Formlabs 45+ materials. Advanced users can even customize time and temperature to fit their specific needs.
Printer compatibility: Designed to fit any part up to 200 x 125 x 245 mm generated on the Form 4, Form 4B, Form 4L, Form 4BL, as well as Form 3, Form 3L, Form 3B, Form 3BL, Form 2
Cure Most Parts in 60 Seconds:
Rapid UV curing and instant heat up for consistent, validated results and effortless post-curing of large Form 4 prints.
60°C in 60 seconds and 80°C in 150 seconds.
Post-cure general purpose resins in just 60 seconds and cure engineering resins in 3-15 minutes.
Consistent, Validated Results:
48 LED array and convective heating system ensure uniform UV and heat exposure.
Delivering 14.5 mW/cm² irradiance and a maximum temperature of 100°C for precise and consistent results.
Easier than Ever
Sleek new design with pre-programmed cure cycles.
Easily cleaned glass turntable.
Side-hinged door to allow easy access within a compact footprint.
Fits the large Form 4 generated parts with its 235mm rotating turntable and 245mm maximum part height.
| Specifications: | Form Cure (2nd Generation) |
| Printer Compatibility | Form 4, Form 4B, Form 3/+, Form 3B/+, Form 2 |
| Dimensions | 33.7 x 40.4 x 37.2 cm (13.3" x 14" x 15.9") |
| Weight | 12.1 kg (26.7 lbs.) |
| Turntable Diameter | 23.5 cm (9.25") |
| Maximum Part Height | 24.5 cm (9.64") |
| Maximum Cure Chamber Temperature | 100 °C (212 °F) |
| Light Source | 48 multi-directional LEDs |
| LED Power | 150 W |
| LED Radiant | 50 W |
| LED Wavelength | 405 nm |
| Power Requirements | Input (NA) 100 - 120V, 50-60 Hz, 15 A |
