Product Description
The SWT fiber laser welders are available in 2 configurations: Class 1 (closed) or Class 4 (open). Choose what works best for your shop! The SWT is specifically designed for the maintenance of medium to small sized molds up to 15.75" square (400mm). The robust design and sturdy working platform gives the operator outstanding comfort and minimal vibration. Controlled via joystick, the working platform moves up or down on the Z-axis with a range of 12.5" (320mm). The X and Y-axis movements are 11.75" and 7.75" respectively (300 x 200mm).
The ergonomic design of the SWT Class 1 (closed) is ideal for prolonged use. Soft armrests, adjustable doors, and adjustable footboard create a comfortable working environment. The stable working platform, on both Class 1 and Class 4 models, minimizes any vibrations, even at the full load capacity of 264 lbs. (120kg). Fiber laser welders offer the highest productivity and efficiency when it comes to processing speeds. They are maintenance-free and with the advantage of having zero downtime.
Made in Italy. Backed by a 1-year manufacturer’s warranty. Installation, training, and service provided by Gesswein Company.
Key Features:
- Available Open or Closed Configuration
- Medium to Small Size Molds
- Pulse shaping software for easy tuning to eliminate porosity, undercut, or sink.
- Programmable Path Settings –Overlap, Line, Radius, Oblique, Fill, Rotating Spindle and More
- Motorized Control of X, Y, and Z Axes (via Joystick)
- Attach a 4th axis for circumferential welding.
- Internet Connection for Remote Service Management and Free Upgrades
|
Model |
SWT 150F |
SWT 300F |
SWT 450F |
|
Item # Class 1 |
833-1876 |
833-1878 |
833-1880 |
|
Item # Class 4 |
833-1870 |
833-1872 |
833-1874 |
|
Source Type |
Fiber |
Fiber |
Fiber |
|
Wavelength |
1070 nm |
1070 nm |
1070 nm |
|
Average Laser Power |
150W |
300W |
450W |
|
Max Peak Power |
1.5kW |
3.5kW |
4.5kW |
|
Max Pulse Energy |
15J |
30J |
45J |
|
Pulse Frequency |
0 - 50 Hz |
0 - 50 Hz |
0 - 50 Hz |
|
Pulse Duration |
0.3 ms - 10 ms |
0.3 ms - 10 ms |
0.3 ms - 10 ms |
|
Laser Spot Diameter |
0.1mm - 2mm |
0.1mm - 2mm |
0.1mm - 2mm |
|
Axis Speed |
0.1mm/s - 25 mm/s |
0.1mm/s - 25 mm/s |
0.1mm/s - 25 mm/s |
|
X Axis Stroke |
11.8" (300mm) |
11.8" (300mm) |
11.8" (300mm) |
|
Y Axis Stroke |
7.9" (200mm) |
7.9" (200mm) |
7.9" (200mm) |
|
Z Axis Stroke |
12.6" (320mm) |
12.6" (320mm) |
12.6" (320mm) |
|
Cooling |
- |
- |
- |
|
Max Load Weight |
264 lbs. (120kg) |
264 lbs. (120kg) |
264 lbs. (120kg) |
|
Max Mold Size |
15.7" x 15.7" x 12.6" (400mm
x 400mm x 320mm) |
15.7" x 15.7" x 12.6" (400mm
x 400mm x 320mm) |
15.7" x 15.7" x 12.6" (400mm
x 400mm x 320mm) |
|
Power Supply |
230V±10%, 1Ph, 1.6kW |
230V±10%, 1Ph, 2.2kW |
230V±10%, 1Ph, 2.8kW |
|
Dimensions (L x W x H) |
33" x 48" x 60" (850 x 1200 x
1500mm) |
33" x 48" x 60" (850 x 1200 x
1500mm) |
33" x 48" x 60" (850 x 1200 x
1500mm) |
|
Weight |
1,235 lbs. (560kg) |
1,235 lbs. (560kg) |
1,235 lbs. (560kg) |
Why Manufacturers Choose Sisma
Founded in Italy in 1961, Sisma is a global leader in high-precision laser machinery for industrial and manufacturing applications. Trusted by manufacturers worldwide, Sisma laser welders are known for their accuracy, process stability, and long-term reliability in demanding production environments. With decades of engineering expertise and proprietary patented technologies, Sisma systems support laser welding applications across industrial manufacturing, tooling and moldmaking, and precision fabrication environments.
