Sunstone Halo™ Articulating Arm Auto Darkening Lens
Sunstone Halo™ Articulating Arm Auto Darkening Lens
SKU: 8300086
|
Non-Stock, Dropship
Price will appear in cart at checkout
Regular price
$595.00
/ Each
Unit price
/
per
Product Specifications
Product Specifications
Brand:
Orion
Country of Origin:
United States of America
Net Weight:
3.3 lbs
Product Description
The Sunstone Halo is an articulating auto-darkening lens system built specifically for permanent jewelry welding, combining 5× magnification, integrated LED lighting, and a fully adjustable arm so you can position your view exactly where you need it. Whether you're welding at a pop-up or at a bench, Halo keeps your workspace open and uncluttered while giving you a clearer, more controlled view of every weld, helping you weld more successfully.
Features
- 5× magnification for enhanced weld visibility
- Auto-darkening lens with Shade 2.5 light state and Shade 12 dark state
- Multi-articulating arm with 6 adjustment points
- Adjustable tension for stable, customizable positioning
- Up to 30" reach above the workspace
- 360° lens orientation capability
- Lightweight aluminum construction
- Table-mounted clamp system for secure setup
- Compatible with Orion Pulse Arc Welders (Zapp®, Zapp Plus, mPulse®, Orion 100c, 150S, 150x, 200x) and other systems capable of sending a weld trigger signal
| Specification | Details |
|---|---|
| Viewing Area | 3.65 in × 3.875 in (92.5 mm × 98.5 mm) |
| Lens Housing Dimensions | 5.0 in × 7.0 in (127 mm × 177 mm) |
| Light State Shade | Shade 2.5 |
| Darkened Shade | Shade 12 |
| Magnification | 5× |
| UV/IR Protection | Always active (even in light state) |
| LED Count | 33 LEDs |
| Light Type | Cool white |
| Power Source | Powered through welder connection |
| Arm Articulation Points | 6 |
| Base Rotation / Lens Head Swivel | Yes |
| Mount Type | Threaded C-clamp |
| Maximum Table Thickness | 2.3 in (58.4 mm) |
| Maximum Reach Above Table | 30 in (762 mm) |
| Maximum Reach Below Table | 20 in (508 mm) |
